LED STREET LIGHT WITH DAY NIGHT SENSOR

LED STREET LIGHT WITH DAY NIGHT SENSOR

Model

LED street Light with Day Night Sensor Available from 16 Watt to 150 Watt

Certification

ISO, CE, RoHS, BIS, LM79 or LM80, TM

Number of LEDs

16/20/24/30/36/50/60/70/90/100/120/150

Dimension



Weight



LED Brand

OSRAM LED3030

Power Consumption

16 watt to 150 watt

LED Lumens Efficiency

140 Lumens / Watt

Beam Angle

120 Degree

LED Working Voltage

+6 VDC

LED Working Current

150mA

Input Voltage

100 – 305 VAC

Operating Frequency

50Hz

Power Factor

0.98

CRI

80

Pole Diameter

40 mm

Maximum Temperature Of Heat sink

65 C

Storage Temperature

35 C

Color

White/Warm White (As per order)

Color Temperature

6500K

Body Type

Pressure die cast Aluminum alloy for housing gear, Extruded aluminum lamp housing (heat sink) for Better heat transmission.

IP rating

IP65

Working Hours

60000

External Load capacity

Upto 300 Watt

Max current Handling

6 A

Warranty

2 Years

Additional Features of Day Night Sensors

  • With best quality and Original components for automatic circuit.
  • Single shot ON-OFF operation.
  • No flickering at load side.
  • Heavy duty and long life circuit.
  • Fit and Forget module.

Electrical Protections for LED Driver

  • Single shot no-load latching protection / output short-circuit protected    with auto-recovery
  • Under voltage protection
  • Output short circuit protection
  • Auto-recovering thermal shutdown with large hysteresis protects
  • Both components and printed circuit board
  • No damage during brown-out conditions

Additional Features

  • Plug & Play Device
  • Corrosion free Body Material
  • Dust proof
  • Fit and Forget Product
  • Easy to Install
  • Easy to maintain
  • Rugged
  • Suitable in any Environmental Condition
  • Save Up to 70% of Electricity
